The Spot CAM+IR payload turns Spot into a powerful inspection tool with purpose-built cameras.
Use Spot CAM+IR to get eyes on remote or hazardous environments while focusing on inspection details that matter.
IR Camera
Integrated radiometric thermal camera
Audio
Two speakers and microphones enable two-way audio
Pan-Tilt-Zoom
PTZ camera with 30x optical zoom
Spherical Camera
360 x 170° view
Lighting
Four pairs of LEDs for illumination
Protection
Roll cage for crash protection
Ports
USB port available for saving image data
Cabling
Protected cabling and sealed electronics
Configuration
Options for front or rear mounting
DIMENSIONS
Length
334 mm (13.1 in)
Width
227 mm (8.9 in)
Height (Front Mount)
357 mm (14.1 in)
Height (Rear Mount)
427 mm (16.8 in)
Weight (Front Mount)
7.5 kg (16.4 lbs)
Weight (Rear Mount)
8.0 kg (19.8 lbs)
360° CAMERA
Field of View (FoV)
360 x 170°
Video Frame Rate
Variable*
Video Storage
No
Video Streaming
Yes
Resolution
10 MP
File Size
31.1 MB
Still Image Format
PPM (Portable Pixel Map)
PTZ CAMERA
2MP, 1080p video
Optical Zoom
30x
Pointing Accuracy
2 degrees
Range of Motion
170°/sec
Tilt Range
-30 to 270°
IR CAMERA
Scene Temp. Range
-40°C to +160°C (HighGain)
Scene Temp. Range (Low Gain)
-40°C to +550°C
Video Speed
7.5 Hz
FoV
69 x 56°
Image Resolution
640 x 512
Accuracy
Radiometric ±5°C
AUDIO
Input
Sennheiser MKE600 shotgun microphone
Storage
Removable 256 GB USB 3.1
ENVIRONMENT
Ingress Protection
IP65
Operating Temperature
-20°C to 45°C
Automate visual and thermal inspects and gain situational awareness in both routine and hazardous situations.
If you want to learn more about Spot CAM+IR and our solutions, reach out to our experts today.
